Containerized Diesel Generator Sets Custom Super Silent Industrial Generator Set

Brand Name:	AIKE POWER
Model Number:	AC688
MOQ:	1
Price:	USD
Supply Ability:	20 set/m

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO

Name:

Containerized Diesel Generator Sets

Alternator Brand:

Stamford/Marathon/Leroy Somer

Container Color:

Custom

Control Panel:

Deif,ComAp,Deepsea

Noise Level:

≤73dB

Output Type:

AC Three Phase

Packaging Details:

plastic wrap

Supply Ability:

20 set/m

Highlight:

Containerized Diesel Generator Sets

Custom Industrial DG Set

Super Silent Industrial Generator Set

Product Description

Containerized Diesel Generator Sets, Industrial Genenerator Set , Container Diesel Generator

In the motor-generator set, two machines were used. As a result, some machine-related losses occur. These losses are very high compared to other techniques.

The whole system is noisy and requires regular maintenance as it contains more rotating parts.

During interruptions, the machine slows down. It may affect the output voltage and frequency.

Generator Standard Compose:

It is expensive and heavy as compared to rotary converters and takes up more space.
The efficiency is significantly lower than that of other devices used for the same purpose.
Since the power factor of the induction motor is low, it needs to be compensated.
The main disadvantage of the MG kit is that it can only be used to convert AC to DC (i.e. it cannot be used to convert DC to AC)

Generator set		Genset Model	AC688
		Rating Power (KW/KVA)	500/626
		Standby Power(KW/KVA)	550/687.5
		Rating Ammeter(A)	902
Diesel engine	General data	Engine model	KTAA19-G6A
		Prime Power(KW/HP)	549/746
		Standby Power(KW/HP)	610/829
		number of Cylinder & Configuration	6 cylinders in line
		Bore X Stroke (mm)	159X159
		Displacement(l)	19
		Compression Ratio	13.9:1
		Governor type	Electronic governor
		Rated RPM	1500
	Exhaust system	Exhaust gas flow(m³/min)	107.5
		Max. Exhaust Gas Temperature(℃)	480
		Max. Exhaust back Pressure(KPA)	10
	Air intake system	Aspiration Type	Turbo & Air-Air cooled
		Max. intake depression(mbar)	6
		Combustion air Volume(m³/min)	39.9
	Fuel system	Rating Fuel Consumption(l/h)	127
	Fuel system	75% full Fuel Consumption(l/h)	95
	Lubrication system	Total oil capacity(l)	50
		Max permissible oil temp(℃)	121
		Oil pressure at rated rpm(KPA)	345 -483
	Cooling system	Total Coolant capacity(l)	117
		Max. temperature of coolant(℃)	104
		Fan cooling air flow(m³/min)	735
Alternator		Alternator model	HCI544F-S
		Rating Voltage(V)	400/230
		Rating Capacity(KW/KVA)	500/625
		Eff.%	95.2%
		Power Factor	0.8
		Exciting type	Brushless self-exciter AVR
		Voltage regulation	±0.5%
		No. of Phase	3 phase 4 wire
		Enclosure Class	IP23
		Class of Insulation	H
Battery		Rating Capacity(AH)	2X180AH 12V
Dimension		Generator set dimension (LXWXH)	3750x1500x1900
Weight		Generator set Net Weight (kg)	5400
