Cummins 600kW Diesel Generator with Automatic Transfer Switch and Soundproof Enclosure for Industrial and Commercial Use

Name

Cummins 600kW Diesel Generator with Automatic Transfer Switch and Soundproof Enclosure for Industrial and Commercial Use

Brand Name: AIKE POWER
Model Number: AC275
MOQ: 1
Price: negotiate
Payment Terms: L/C,T/T
Supply Ability: 50 set/m
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
ISO,OEM
Type:
600kW Diesel Generator
Controller:
Deepsea/Deif/ComAp
Engine Brand:
Yuchai
Frequency:
50/60Hz
Fuel Tank Capacity:
Customized
Voltage:
220/380V , 230/400V , 240/415V(adjustable)
Alternator Brand:
Stamford/Leroy Somer/Marathon
Warranty:
1 Year/1000 Hours
Packaging Details:
plastic wrap or wooden case
Supply Ability:
50 set/m
Highlight:

600kW diesel generator with ATS

,

industrial diesel generator soundproof enclosure

,

commercial Cummins generator with warranty

Product Description
Cummins 600kW Diesel Generator with Automatic Transfer Switch and Soundproof Enclosure
Industrial-grade 600kW diesel generator designed for commercial and industrial applications, featuring automatic transfer switch capability and soundproof enclosure.
600kW Diesel Generator | Industrial Diesel Generator | Diesel Powered Generator
Technical Overview
When operating without load, the generator's armature current is zero (no-load operation). The stator's three-phase winding produces no-load electromotive force E0 (three symmetrical) induced by the excitation current If. The relationship between E0 and If follows the synchronous generator's no-load characteristic curve.
Available Options
Automatic Transfer Switch (ATS) available as optional equipment
Controller brands: UK Deepsea, Czech ComAp, Denmark DEIF, Smartgen China
Engine options: Cummins, Perkins, Yuchai, Shangchai, Volvo and others
Standard Features
  • High-temperature radiator (40℃ environment capability)
  • Driving belt cooling fans with safety shield
  • 24V charging generators
  • Single bearing generator with IP23 protection and H insulation
  • Shock absorber system
  • Dry air filter, fuel filter, and oil filter
  • Power output circuit breaker
  • Standard control panel
  • 12V battery with connection cables
  • Battery charger
  • Complete exhaust system (pipe, bellows, flange, muffler set)
  • 8-hour base fuel tank
  • Complete documentation and manuals
Technical Specifications
Generator Set Specifications
Genset Model AY825
Rating Power (KW/KVA) 600/750
Standby Power (KW/KVA) 660/825
Rating Ammeter (A) 1088
Engine Specifications
Engine Model YC6TD1000-D30
Prime Power (KW/KVA) 668/835
Standby Power (KW/KVA) 735/919
Cylinder Configuration 6 cylinders in line
Bore × Stroke (mm) 200 × 210
Displacement (l) 19.598
Compression Ratio 14:1
Governor Type Electric start
Rated RPM 1500
Alternator Specifications
Alternator Model AK-600-4
Rating Voltage (V) 400/230
Rating Capacity (KW/KVA) 600/750
Efficiency 87.5%
Power Factor 0.8
Exciting Type Brushless self-exciter, AVR
Voltage Regulation ±0.5%
Phase Configuration 3 phase 4 wire
Enclosure Class IP23
Class of Insulation H
Physical Specifications
Dimensions (L×W×H mm) 4663 × 1500 × 2100
Net Weight (kg) 7228
Battery Capacity 4 × 150AH 12V
