Affordable 1000kVA 800kW Yuchai Diesel Generator 50Hz with Warranty

Name: Affordable 1000kVA 800kW Yuchai Diesel Generator 50Hz with Warranty
Brand: Guangdong Aike Power Technology Co., Ltd
SKU: AY412
Availability: InStock

Brand Name:	AIKE POWER
Model Number:	AY412
MOQ:	1
Price:	USD
Supply Ability:	20 set/m

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO,OEM

Name:

300kw Yuchai Diesel Generator Set

Control Panel:

ComAp,Deif,Deepsea

Controller Type:

Digital

Model:

AY412

Rated Power:

5KW~3000KW

Speed:

1500rpm

Start Method:

Electric Start

Style:

Open-shelf

Frequency:

50Hz

Engine Type:

4 Cylinders In Line

Packaging Details:

plastic wrap

Supply Ability:

20 set/m

Highlight:

1000kVA Yuchai diesel generator with warranty

800kW diesel generator set 50Hz

affordable Yuchai diesel generator set

Product Description

Affordable 1000kVA 800kW Yuchai Diesel Generator 50Hz with Warranty

Yuchai power generator set with high voltage YC6K500-D30. Available in 50Hz/1500RPM with adjustable voltage (380/220V, 400/230V, 415/240V) or 60Hz/1800RPM with voltage options (220/127V, 380/220V, 440/254V). Multiple configurations available including Open Type, weatherproof type, soundproof type, and trailer type.

Control System Options: ATS available from ABB, Schneider Electric, SOCOMEC & Delixi brands.

Controller Brands: UK Deepsea, Czech ComAp, Denmark DEIF, Smartgen China.

Generator Standard Components

Yuchai Engine, model YC6K500-D30
40℃ environmental temperature water tank radiator with belt-driven cooling fans and safety shield
24V charging generator
Single bearing generator with IP23 protection and H insulation
Shock absorber system
Dry air filter, fuel filter, and oil filter
Power output circuit breaker
Standard control panel
12V battery with connection cables
Battery charger
Complete exhaust system with pipe, bellows, flange, and muffler
8-hour base fuel tank
Complete documentation and manuals

Technical Specifications

Generator Set

Genset Model	AY412
Rating Power (KW/KVA)	300/375
Standby Power (KW/KVA)	330/412
Rating Ammeter (A)	544

Diesel Engine

Engine Model	YC6K500-D30
Prime Power (KW/KVA)	335/419
Standby Power (KW/KVA)	370/463
Number of Cylinders & Configuration	4 cylinders in line
Bore X Stroke (mm)	6-129*155
Displacement (l)	12.16
Compression Ratio	16.5:1
Governor Type	Electric start
Rated RPM	1500

Exhaust System

Exhaust Gas Flow (m³/min)	33
Max. Exhaust Gas Temperature (℃)	550
Max. Exhaust Back Pressure (KPA)	10

Air Intake System

Aspiration Type	Turbocharged intercoolant
Max. Intake Depression (KPA)	12
Combustion Air Volume (m³/min)	33

Fuel System

Rating Fuel Consumption (l/h)	50.4
75% Full Fuel Consumption (l/h)	37.4

Lubrication System

Total Oil Capacity (l)	21
Max Permissible Oil Temp (℃)	97
Oil Pressure at Rated RPM (KPA)	345-413

Cooling System

Total Coolant Capacity (l)	10
Max. Temperature of Coolant (℃)	550
Fan Cooling Air Flow (m³/min)	125

Alternator

Alternator Model	AK-300-4
Rating Voltage (V)	400/230
Rating Capacity (KW/KVA)	300/375
Efficiency (%)	91.5%
Power Factor	0.8
Exciting Type	Brushless self-exciter, AVR
Voltage Regulation	±0.5%
Number of Phase	3 phase 4 wire
Enclosure Class	IP23
Class of Insulation	H

Battery

Rating Capacity (AH)

2X150AH 12V

Dimensions & Weight

Generator Set Dimension (LxWxH)	3243x1100x1900
Generator Set Net Weight (kg)	2950

Frequently Asked Questions

Q: Do you offer OEM service?

A: Yes

Q: What is your payment term?

A: 30% T/T in advance, 70% balance when receiving B/L copy, Or 100% irrevocable L/C at sight.

Q: What is your lead time?

A: About 15-25 days after receiving advance deposit or original L/C.

Q: What certificates do you have?

A: We have ISO and can apply for specific certificates for different countries such as SONCAP for Nigeria, COI for Iran, SASO for Saudi Arabia, etc.

Q: What warranty do you provide?

A: One year or 1200 hours' running whichever occurs first. During the guarantee period, we will supply free easily damaged parts for possible problems except for incorrect operation. After expiration, we supply cost spare parts for genset maintenance.
